astm a335 carbon seamless steel pipes tubes Factory direct sales
10# 20# 35# 45# 16Mn 27SiMn 40Cr
Hot-rolled seamless steel pipe is a large category of seamless steel pipe, which is divided according
to the production method. Hot rolling is relative to cold rolling, cold rolling is carried
out rolling at room temperature, and hot rolling is carried out
rolling at the crystallization temperature.
A seamless steel pipe is a circular pipe having a hollow section and no seams around it. The seamless steel pipe is made of carbon steel, alloy steel,
stainless steel ingot or solid tube blank, and then is made by hot
rolling, cold rolling or cold drawing
Seamless steel is stronger than welded pipes, making it more expensive because of the higher production cost.
On the other hand, welded steel pipes are easier to manufacture due
to the cheaper cost of production and raw material availability.
Performance and Usage. Seamless steel pipe has better pressure capacity, strength is
higher than ERW welded steel pipe. So it is widely applied in high pressure equipment, and thermal,
boiler industries. Generally the welding seam of the welded steel
pipe is the weak point, the quality affect overall performance.
Slotted steel pipes and seamless steel pipes are divided according
to the processing form. The seamed steel pipes are generally welded. The seamless steel pipes are cold drawn and hot-rolled. The carbon steel pipes are in terms of materials, and the
galvanized pipes are welded pipes.
Product details
| proudanct name | ASTM106 GrB hot rolled seamless carbon steel pipe tubing 89mm |
| Steel Grade | GB JIS ASTM BS DIN |
| Surface | Painting |
| Delivery Time | 22-30 days |
| Length | 12M 6m |
| Grade | ASTM106GrB |
| Alloy Or Not: | Non-Alloy |
| Processing Service | Welding Punching Cutting |
| Technique | Hot Rolled |
| Shape | Round Shape |
Size | OD | 1/2” -24” (13.7mm-609.6mm) |
Wall Thickness | 1.6mm-28mm
SCH20,SCH40,STD,XS,SCH80,SCH160,XXS |
Length | 5.8M Length, 6M Length or 12M Length or as requested |
Steel material |
20#,16Mn,St37,St52,St44, etc
|
Standard | API 5L,ASTM A53,ASTM A106,GB/T 8163,GB/T 8162,DIN 17175,DIN 2448
etc |
Usage | 1)low pressure liquid, water, gas, oil, line pipe
2)construction
3)fence, door pipe |
Ends | 1) Plain
2) Beveled
3) Thread with Coupling or cap
4) Chamfer
5) Groove
6) Screw |
End protector | 1) Plastic pipe cap
2) steel socket |
Surface Treatment | 1) Bared
2) Black Painted (varnish coating)
3) hot dipped Galvanized
4) Oiled
5) PE,3PE, FBE, corrosion resistant coating, Anti corrosion
coating. |
Technique | |
Type | cold drawn, hot rolled, welded |
Section Shape | Round |
Inspection | With Hydraulic Testing, Eddy Current , Infrared Test |
Port of Shipment | Xingang Port, Tianjin, China |
Date of Delivery | 20 days after confirmation or According To The Quantity And
Specification Of Eac |
Application
ASTM Specification A106 covers seamless carbon steel nominal wall pipe for high-temperature
service, suitable for bending, flanging and similar forming
operations. NPS 1-1/2 and under may be either hot finished or cold drawn.
S/A 106 Spec Sheet A106 Pipe Specifications A/SA106 NPS 1/4"- 30"
Schedules 10 through 160, STD, XH and XXH Scope ASTM A106 Seamless
Pressure Pipe (also known as ASME SA106 pipe) covers seamless
carbon steel nominal wall pipe for hightemperature service.
Suitable for bending, flanging and similar forming operations. NPS
1-1/2" and under may be either hot finished or cold drawn. NPS 2"
and larger shall be hot finished unless otherwise specified.
Process Killed steel, with primary melting process being
open-hearth, basic-oxygen, or electric-furnace, possibly combined
with separate degassing or refining. Steel cast in ingots or strand
cast is permissible. Hot-finished pipe need not be heat treated.
Cold-drawn pipe shall be heat treated after the final cold draw
pass. Chemical Requirements
Grade A Grade B Grade C Carbon max. % 0.25 0.30 0.35 *Manganese %
0.27 to 0.93 *0.29 to 1.06 0.29 to 1.06 Phosphorous, max. % 0.035
0.035 0.035 Sulfur, max. % 0.035 0.035 0.035 Silicon, min.% 0.10
0.10 0.10 Chrome, max. % 0.40 0.40 0.40 Copper, max. % 0.40 0.40
0.40 Molybdenum, max. % 0.15 0.15 0.15 Nickel, max. % 0.40 0.40
0.40 Vanadium, min.% 0.08 0.08 0.08 Total of Cr, Cu, Mo, Ni, and V
shall not exceed 1%
